7-8
2) Menu Screen (LCD)
Displays the set-ups and the main & sub menus selected.
Set-up
There are 10 types of set-up information. Four will be listed at a time. Press UP or DOWN on the right side of
the LCD screen to move to another screen.
NO: memory number of the selected design
STITCH: number of total stitches in the selected design
COLOR: number of color changes (needle bars) in the design
JUMP: number of jump stitches in the design
X[mm]: the X dimension (left to right) of the selected design
Y[mm]: the Y dimension (top to bottom) of the selected design
ANGLE: the selected orientation of the design by degrees
MIRROR: if the reverse function is selected
X_SCALE: if the design has been scaled up or down in the X direction
Y_SCALE: if the design has been scaled up or down in the Y direction
The above data are accurate based on instant calculation.
Sub Menus
Main menus are selected by keys on the control panel. Sub menus will appear on the screen at your selection
of a main menu. All sub menus cannot be indicated on a single screen. Use UP/DOWN buttons to move to
another screen.
Ex) selection of basic set-up
NO : 8
STITCH : 16850
COLOR : 6
JUMP : 118
X [mm] : 83.4
Y [mm] : 101.6
ANGLE : 45
MIRROR : OFF
X_SCALE : 100
Y_SCALE : 100
1] X_SCALE : 100%
2] Y_SCALE : 100%
3] ANGLE : 0
4] MIRROR : NO MIRROR
