Page | 13
PV String Input Reverse Polarity
Protection
Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over Current Protection Integrated
Output Shorted Protection Integrated
Output Over Voltage Protection Integrated
Certifications and Standards
Grid Regulation
VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116,
IEC61727,
RD1699:2011, XP C15-712-3:2019-05
Safety Regulation IEC62109-1, IEC62109-2
EMC EN61000-6-1, EN61000-6-3
General Data
Operating Temperature Range -25~60°C, >45°C Derating
Cooling Fan
Noise <30dB
Communication with BMS RS485; CAN
Weight 20.5kg
Size (Length x Width x Height) 580 x 330 x 208 mm
Protection Degree IP65
Warranty 5 years
SUNSYNK-8K-SG01LP1 and SUNSYNK-8K-SG02LP1
Model SUNSYNK-8K-SG01LP1 / SUNSYNK-8K-SG02LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range 40~60V
Max. Charging Current 190A
Max. Discharging Current 190A
Charging Curve 3 Stages/Equalisation
External Temperature Sensor Optional
Charging Strategy for Li-Ion Battery Self-Adaptation to BMS
PV String Input Data
Max. DC Input Power 10400W
PV Input Voltage 370V (100V~500V)
MPPT Range 125~425V
Full Load DC Voltage Range 240~425V
Start-up Voltage 150V
PV Input Current 22A+22A
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 2+2
AC Output Data
Rated AC Output and UPS Power 8000W
Max. AC Power 8800W
Peak Power (off-grid) 2 times of rated power, 10 S
AC Output Rated Current 33.4A/35A
Max AC Output Current 36.7A/38.5A
Max Continuous AC Passthrough 50A
Output Frequency and Voltage
50/60Hz; 120/240Vac (split phase), 208Vac (2/3), 230Vac (single
phase)
Grid Type Split phase, 2/3 phase, single phase
Current Harmonic Distortion THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
MPPT Efficiency 96.50%
