Page | 14
Euro Efficiency 99.90%
Protection
PV Arc Fault Detection Integrated (Except European Type)
PV Input Lightning Protection Integrated
Anti-islanding Protection Integrated
PV String Input Reverse Polarity
Protection
Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over-Current Protection Integrated
Output Shorted Protection Integrated
Output Over Voltage Protection Integrated
Certifications and Standards
Grid Regulation
UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98,
G99, IEC61683, IEC62116, IEC61727
Safety Regulation IEC62109-1, IEC62109-2
EMC EN61000-6-1, EN61000-6-3, FCC 15 Class B
General Data
Operating Temperature Range -25~60°C, >45°C Derating
Cooling Fan
Noise <30db
Communication with BMS RS485; CAN
Weight 32kg
Size (Length x Width x Height) 670 x 420 x 233 mm
Protection Degree IP65
Installation Style Wall-mounted
3.1. System Diagram
