80-0067-00-MO-RevF 2017-10-03 SunTech CT40 User Manual | 15
If successful, the icon will flash on and off with check mark.
If not successful, it will flash on and off with X.
Adult or Child Patient Selection
Press and hold toggle button for 4 seconds, until selection knob starts flashing. Release toggle button, and use the
selection knob to select the icon needed. Selected icon will blink after 1 second. Press the selection knob to confirm
the selection.
: Adult BP Mode icon. This icon is illuminated when the Adult BP mode is selected.
: Pediatric BP Mode icon. This icon is illuminated when the Pediatric BP mode is selected. The CT40 will remain in
the selected patient mode until a new mode is selected.
Heart Rate and MAP Measurements
♥: Measured in BPM (Beats per minute), is illuminated when a heart rate is shown in the heart rate display.
MAP: Measured in mmHg is illuminated when a MAP value is shown (only if MAP functionality is enabled). NOTE:
This is a factory setting. MAP is not available in the U.S.
Pulse Oximetry Measurement Display
: Expressed in % of arterial oxyhemoglobin
Temperature Measurement Settings and Results Display
: Body temperature in either Fahrenheit or Celsius (user selectable)
: Cold Pre-heat mode
: Predictive mode
: Direct mode
: Human thermometry mode. Temporal (arrow on left side of head), Oral (arrow on right side of head), Axillary
(arrow under arm), or Rectal (arrow pointing to rectum).
: Object thermometry mode. Illuminates when object thermometry mode has been selected.
: Apply temp probe cover
