80-0067-00-MO-RevF 2017-10-03 SunTech CT40 User Manual | 22
Auscultatory SphygMode
Example shows Auscultatory SphygMode setup display. Three-digit number is the target cuff inflation pressure setting.
The default is 160 mmHg.
Press the Mode Toggle Button until
you see the Auscultatory SphygMode Icon .
From single measurement mode, that will be two
button presses.
The pressure setting icon and Selection Knob will
flash. To keep the default maximum cuff inflation setting of
160 mmHG, press the Knob. Or choose another pressure level
between 100-280 mmHG and press the Knob to select. The
device will remember the pressure setting and display the
same pressure setting the next time SphygMode is used.
Step 4: How to Measure BP in Each Mode
When in the appropriate home screen (see above)
Averaging Measurement Mode
Ensure values are cleared from
display except for SYS value
representing current pressure in
cuff.
Press Start/Stop Button
.
Inflate/deflate cycle proceeds
automatically until results are
displayed.
A long beep will sound to indicate
measurement is complete.
When selecting this mode the
will flash to allow the user to decide
how many reading they would like
averaged.
Select number of readings by
rotating the selection knob and
push the selection knob to set the
number of readings.
The minute number will flash and
the user can select how many
minutes until the first reading starts
by rotating and pushing the
selection knob.
The user can then select how often
the readings will occur, and select
this by rotating the knob and
pushing the knob to selection
wanted.
Put stethoscope over artery.
Press Start/Stop to
inflate cuff automatically. Similar to
an analog sphyg gauge, the display
shows current pressure in cuff.
When cuff reaches max pressure,
deflation will begin automatically.
Listen for K-sounds while watching
displayed pressure. Note SYS and
DIA.
Press Start/Stop again to
quickly dump remaining pressure
from the cuff.
