9. Reporting to server
This Chapter explains how device makes a report and sends it to theserver.
Location Report
Field
Marks
Meaning
HDR
“ST910”
Model Name
RPT_TYPE
“Location”
Report Type
DEV_ID
6 or 9 char.
Digits ID of device. It is a part of IMEI. Please check the
“DEV_ID_TYPE” setting.
SW_VER
3 char
Software version.
DATE
String
YYYYMMDD
TIME
String
HH:MM:SS, 24 hours format, UTC
CELL
String
Information of Cell ID
Cell ID(4digits hex) + Location Code ID(4 digits hex) + Serving Cell
BSIC(2 digits decimal).
This information will be here only if “ PROT_TYPE = 1”
LAT
String
Latitude in degree
LON
String
Longitude in degree
SPEED
String
Speed over the ground in Km/h
COURSE
String
Track angle in degrees
FIX
‘0’ or ‘1’
0: GPS is not fixed
1: GPS is fixed
F: The GPS Module has a problem.
DISTANCE
String
Moving distance value (Unit : m).
This information will be here only if “ PROT_TYPE = 1”
BATTERY_VOLT
String
If “ PROT_TYPE = 1” Voltage of Battery in percentage (%)
If “ PROT_TYPE = 0”  Battery voltage
IMMEDIATE
Digit
0: Report is sent from the memory
1: Report is sent on-line
MODE
Digit
0: Parking Mode
1: Driving Mode
MSG_NO
String
Message number.
After 9999, message number initialized to zero
MODEL
DISTANCE
CELL
2 Char
String
String
Device Model (According to table model)
Moving distance value (Unit : m).
This information will be here only if “ PROT_TYPE = 0”
Information of Cell ID
Cell ID(4digits hex) + Location Code ID(4 digits hex) + Serving Cell
