10
Note: 1. Our company’s extending wire for electrode material No. is 7202-F94009-BK
and 7202-RG-58
1.) If temperature probe is not used, the material No. is 7202-RG-58.
2.) If temperature probe is used, the material No. is 7202-F94009-BK.
2. If temperatures probe 8-26-3(NTC30K) or 8-26-8(PT1000) is used for two-wire
distribution, the black wire terminal should be forbidden.
〔2〕
Three-wire distributing system
IN terminals Terminal
No.
OUT terminals Terminals on controller
Electrode central spindle 1 Central spindle extending wire
for electrode
GLASS
Ground Rods 2 GND GND
Electrode network cable 3 Green wire extending wire for
electrode
REF
Temperature probes red
wire
4 Red wire extending wire for
electrode
T/P
Temperature probes
green wire
5 Green wire extending wire for
electrode
GND
Alternative 6、7 Alternative ----
Note: 1. The black wire on the temperature probes of 8-26-3(NTC30K) or 8-26-8(PT1000) is
used as special wire for Ground Rods to be connected at terminal 2.
2. The extending wire for electrode that has a temperature probe or ground rod is
marked with material number 7202-F94009-BK.
