9 — Air filter clogged indicator lamp 10— Flameout control indicator
11— Cooling Water temperature indicator 12— Sound cancel button
13— High speed traveling control button 14— Working Light control button
15— Screen switch button 16— Fuel level indicator
17— Excavator monitor 18— Fuel level warning indicator
19
When the start switch is on position 3 (refer to start switch), auto-check start, all the indicators
come on for about 2 seconds.
1 —Automatic idling indicator
This symbol light comes on when the system is in automatic idling. SWE17B-3 has no the
function of automatic idling
2 —Working Light indicator
This symbol light comes on when the working light is on work.
3 — Engine oil pressure warning indicator
This indicator indicates the engine oil pressure. When the pressure is normal, there’s no
indication; it lights on when the pressure is low and meanwhile, buzzer will warn.
4 —Work hour meter
The number on this device is the work time of this machine.
5 —Engine speed meter
The speed of the working engine.
6 — Electric charging indicator
This symbol light comes on when the generator working condition is abnormal; and it turns off
when generator becomes normal.
7 — High speed traveling indicator
This indicator lights up when machine is traveling at high speed; and it will not light up when the
machine is traveling at low speed.
8 — Warm-up indicator
If the machine has to start in cold weather, put the key at warm-up position and this signal will
light up; at the same time, the screen shows “warming up”, after 15second, it shows “warming
up finish”.
9 — Air filter clogged indicator lamp
When the air filter core is clogged, red indicator light comes on. Please clean or replace outer
core.
10 —Flameout control indicator
— Cooling water temperature warning indicator
Check operation control
This symbol light comes on when the engine working condition is abnormal(the engine oil
