If the control lever comes back to the neutral position while it is
traveling down the slope, the machine will automatically stop.
If the machine slides while traveling up on the slope, use the pulling
power of the boom to help the machine clime up the slope.
If engine stops accidentally while traveling down the slope, set the
control lever back to the neutral position to stop the machine, lower the
bucket to the ground to block the machine and then restart the machine.
7) The machine must travel in the pose shown in fig 3-17 when traveling up on a slope of 15°
or more.
8) The machine should travel at low speed and in a
pose shown in FIG. 3-18 when it is traveling down
on a slope of 15° or more.
3.5 EXCAVATION
Working condition
When dig lengthways with backhoe, make the drive
wheel backward and guide wheel forward. (as figure)
In order to guarantee safety in quarry working, make
the drive wheel backward and guide wheel forward.
Pilot handles control
1 — Left pilot handle
2 — Right pilot handle
1
2
FIG. 3-18
20～30cm
