SUNWARD SWE20F 2019 - Travel with Handle Control

37
FIG.3-11
In order to protect travel
mechanism, avoid turning while
backing as possible as you can.
3) Turning in one point
 Turn left (FIG. 3-9): Treadle right pedal 2 forward
and treadle left pedal 3 backwards. (FIG. 3-6)
 Turn right (FIG. 3-10): Treadle right pedal 4
backwards and treadle left pedal 1 forward. (FIG.
3-6)
4) Turning with one side crawler (FIG.3-11)
 Turn left: treadle right pedal 2 forward. (FIG. 3-8)
 Turn right: treadle left pedal 1 forward. (FIG. 3-8)
3.4.2 TRAVEL WITH HANDLE CONTROL
If the machine hairlike traveling is needed, you can
insert two attached handles to carry out hand control.
This method is safe and reliable and fits for loading and
unloading machine to trailer.
FIG.3-10
FIG 3-9
FIG.3-12
