Operation
900285-00 11/2014
Innovative Hearth Products
Superior
TM
DRT3000 Series Direct-Vent Gas Fireplaces
71
REPLACEMENT PARTS
Table 52: Installer Replacement Parts
Description
33” Models 35” Models 40” Models 45” Models
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
1 Electronic Pilot Assembly, Natural Gas H7268 1 H7268 1 H7268 1 H7268 1
2 Electronic Pilot Assembly, Liquid Propane H7269 1 H7269 1 H7269 1 H7269 1
3 Electronic DFC Wire Harness Assembly H8601 1 H8601 1 H8601 1 H8601 1
4 Electronic DFC Ignition Board H7272 1 H7272 1 H7272 1 H7272 1
5 Electronic Power Transformer H8006 1 H8006 1 H8006 1 H8006 1
6
Electronic Battery Holder
(for backup batteries)
H8803 1 H8803 1 H8803 1 H8803 1
7 Electronic Ground Wire H7278 1 H7278 1 H7278 1 H7278 1
8 Electronic ON/OFF Switch 27K30 1 27K30 1 27K30 1 27K30 1
9 Millivolt Pilot Assembly, Natural Gas 69L17 1 69L17 1 69L17 1 69L17 1
10 Millivolt Pilot Assembly, Liquid Propane 69L18 1 69L18 1 69L18 1 69L18 1
11 Millivolt Piezo Igniter 10K86 1 10K86 1 10K86 1 10K86 1
12 Millivolt Piezo Igniter Wire 56L21 1 56L21 1 56L21 1 56L21 1
13 Millivolt Pilot Generator 60J79 1 60J79 1 60J79 1 60J79 1
14 Millivolt Thermocouple 74L57 1 74L57 1 74L57 1 74L57 1
15 Millivolt Pilot Tube 74L56 1 74L56 1 74L56 1 74L56 1
16 MIllivolt Electrode and Cable H6212 1 H6212 1 H6212 1 H6212 1
17 Orifice Holder H7257 1 H7257 1 H7257 1 H7257 1
18 Gas Flex Line Connector 93L32 1 93L32 1 93L32 1 93L32 1
19 Gas Valve, Electronic, Natural Gas H6209 1 H6209 1 H6209 1 H6209 1
20 Gas Valve, Electronic, Liquid Propane 88J53 1 88J53 1 88J53 1 88J53 1
21 Gas Valve, Millivolt, Natural Gas F1833 1 F1833 1 F1833 1 F1833 1
22 Gas Valve, Millivolt, Liquid Propane F1834 1 F1834 1 F1834 1 F1834 1
23 Logset F1883 1 F1829 1 F1830 1 F1884 1
24 Vent Restrictor Base H8987 1 H8987 1 H8987 1 H8987 1
25 Vent Restrictor Wing H8988 1 H8988 1 H8988 1 H8988 1
26 Door Latch Assembly H6135 1 H6135 2 H6135 2 H6135 2
27 Split Flow Valve H8996 1 H8996 1 H8996 1 H8996 1
28 Hi-Low Switch J7359 1 J7359 1 J7359 1 J7359 1
29 On/Off Switch (Split Flow) J7360 1 J7360 1 J7360 1 J7360 1
30 Wall Switch Harness (Electronic) J7358 1 J7358 1 J7358 1 J7358 1
31 Vent Stopper Plug J7356 1 J7356 1 J7356 1 J7356 1
32 Burner Assembly J7402 1 F1843 1 F1844 1 F1844 1
33 Superior
TM
Square Grate H7719 1 H7719 1 H7720 1 H7720 1
34 Manning Glass Gasket F2116 1 F2116 1 F2116 1 F2116 1
35 Wall Plate J7401 1 J7401 1 J7401 1 J7401 1
36 Switch Jumper (Split Flow) J7369 1 J7369 1 J7369 1 J7369 1
37 25” Wall Switch Harness H8931 1 H8931 1 H8931 1 H8931 1
To Next Page
