A2SDV-8C/-12C+/-16C-TLN5F User's Manual
Note: Table is continued on the next page.
Quick Reference Table
Jumper Description Default Setting
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open (Normal)
JI
2
C1/JI
2
C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled)
JNCSI1 IPMI Shared LAN Port Selection ON (short): LAN1, OFF (open): LAN2
JPG1 Onboard VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1 GbE Enable/Disable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JPTG1 LAN2/3/4/5 10GbE Enable/Disable Pins 1-2 (Enabled)
JSEL1 PCI-E Slot Selection Pins 1-2: Slot 7, Pins 2-3: Slot 6
JWD1 Watch Dog Timer Pins 1-2 (Reset)
LED Description Status
LED1 Power LED Solid Green: Power On
LEDBMC BMC Heartbeat Blinking Green: BMC Normal
UIDLED1 UID LED Solid Blue: Unit Identied
Connector Description
BT1 Onboard Battery
COM1 COM Port (on the I/O back panel)
COM2 COM Header
FAN1 - FAN4, FANA, FANB System Fan Headers
IPMI_LAN Shared IPMI LAN Port (Default: shared with LAN1)
I-SATA0-1 Intel® PCH SATA 3.0 Ports (I-SATA0: SuperDOM)
JD1 Speaker Header (Pins 1-4: Speaker)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 System Management Bus Header (for IPMI only)
JL1 Chassis Intrusion Header
JMD1 M.2 B-Key PCIE3/SATA3/USB3 Connector
JMD2 M.2 M-Key PCIE3/SATA3 Connector
JPI
2
C1 Power Supply SMBus I
2
C Header
JPH1 4-pin Power Connector for HDD use
JPW1 24-pin ATX Power Connector
JPV1 4-pin 12V DC Power Connector (To provide alternative power for a special enclosure when
the 24-pin ATX power is not in use.)
JRT3 Thermal Diode 1
JRT4 Thermal Diode 2
