14
A2SDV-8C/-12C+/-16C-TLN5F User's Manual
Note: The table above is continued on the next page.
Motherboard Features
CPU
Intel® Atom SoC C3000 Series (FCBGA1310) Processor
Memory
Supports up to 256GB of RDIMM and 64GB of Non-ECC/ECC UDIMM DDR4 memory with speeds of up to 2400MHz.
On select SKUs, 2400MHz modules can be used but will operate at a lower speed.
DIMM Size
4GB, 8GB, 16GB, 32GB, and 64GB
Expansion Slots
Two (2) PCI-E 3.0 x8 slots option (SLOT6 or SLOT 7 only)
One (1) M.2 PCI-E 3.0 x2 slot (M-Key)
One (1) M.2 PCI-E 3.0 x2 slot (B-Key)
Network
Intel i210AT Gigabit Ethernet Controller
Intel X557-AT4 10Gigabit Ethernet Controller
Baseboard Management Controller (BMC)
ASpeed AST2400 Baseboard Controller (BMC) supports IPMI 2.0
One (1) IPMI LAN port (shared with Intel i210AT LAN1)
Graphics
Graphics controller via ASpeed AST2400 BMC
I/O Devices
Serial (COM) Port One (1) RJ45 serial port (COM1) on back panel
Serial (COM) Header One (1) serial header (COM2)
SATA 3.0 Four (4) SATA 3.0 ports (two via the M.2 connector)
Peripheral Devices
Four (4) USB 3.0 ports on the I/O back panel (USB0/1/2/3)
Two (2) USB2.0 ports in one internal header (USB4/5)
One (1) USB 3.0 Type A header (USB6)
BIOS
128Mb AMI BIOS® SPI Flash BIOS
Plug and Play (PnP), SPI dual/quad speed support, real time clock (RTC) wakeup, ACPI 3.0, BIOS rescue hot-key, and
SMBIOS 2.7
