SuperServer 4029GP-TRT/TRT2/TRT3 User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 4029GP-TRT/TRT2/TRT3.
The 4029GP-TRT/TRT2/TRT3 is based on the X11DPG-O motherboard and the
is used for each system.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description Part Number Quantity
2U Active CPU Heat Sink with Narrow Bolster Plate Mounting
Mechanism
SNK-P0068APS4 2
Black 3rd generation hot-swap 2.5" HDD trays MCP-220-00047-0B 24
2U hybrid backplane for 20xSAS3/SATA3 and 4xSAS3/SATA3/NVMe BPN-SAS3-216A-N4 1
PCI-E Daughterboard for 4029GP-TRT2 system only MBD-X10DRG-O-PCIE-P 1
PCI-E Daughterboard for 4029GP-TRT system only MBD-X9DRG-O-PCIE-P 1
PCI-E Daughterboard for 4029GP-TRT3 system only MBD-X11DPG-O-PCIE-P 1
Riser cards RSC-X9DRG-O 4
1U 2000W Redundant Titanium Power Supplies PWS-2K05A-1R 4
92 x 92 x 38-mm, 11.5K RPM, middle fans with housing FAN-0151L 8
Rail set for 4U 17.2" Width MCP-290-00057-0N 1
1.2 Unpacking the System
Inspect the box the SuperServer 4029GP-TRT/TRT2/TRT3 was shipped in and note if it was
the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
Be sure to read the precautions and considerations noted in Appendix B.
