9
Chapter 1: Introduction
1.3 System Features
The following table provides you with an overview of the main features of the
System Features
Motherboard
X11DPG-O
Chassis
SC418GTS-R4000BP2
CPU
Dual Intel® 81xx/61xx/51xx/41xx/31xx or 82xx/62xx/52xx/42xx/32xx series processors
Socket Type
Socket P0-LGA3647
Memory
Up to 6 TB of 3DS Load Reduced DIMM (3DS LRDIMM)/Load Reduced DIMM (LRDIMM)/3DS Registered
DIMM (3DS RDIMM)/Registered DIMM (RDIMM) DDR4 (288-pin) ECC 2933/2666/2400/2133 MHz speed and
up to 128 GB size at 1.2V in 24 slots.
Chipset
Intel PCH C622 chipset
Expansion Slots
Up to 12 PCI-E 3.0 slots
Hard Drives
Up to 24 2.5" drives (8 are connected by default)
Power
Four 2000W power supplies
Other
ASpeed AST 2500 BMC
Form Factor
4U Rack mount server
Dimensions
(WxHxD) 17.2 x 1.7 x 23.5 in. (437 x 43 x 597 mm)
