SuperServer E200-8D User's Manual
2.2 Accessing the System
The SC101F features a removable top cover to access to the inside of the chassis.
Removing the Top Cover
1. Power down the system as described in section 2.1.
2. Remove the two screws that hold the cover in place.
3. Slide the cover sideways as illustrated above to release the front and rear cover hooks
from the chassis.
4. Lift the cover up and off the chassis.
Caution: Except for short periods of time, do not operate the server without the cover in
.
Figure 2-1. Removing the Chassis Cover
2
3
