8
SuperServer E200-8D User's Manual
System Features
Motherboard
X10SDV-6C-TLN4F
Chassis
Compact Embedded Mini ITX Box, SC101F
CPU
Intel Xeon D-1528 SoC (System on a Chip) in the FCBGA1667 format; CPU TDP support 35W, 9MB cache, 6
Cores, 12 Threads, 1.9-2.2GHz
Cooling
Two 4-cm chassis fans and one additional optional fan, plus a passive CPU heat sink
Memory
Four DDR4 DIMM sockets; supports up to 128GB DDR4 ECC RDIMM or up to 64GB DDR4 ECC/non-ECC
UDIMM; Memory Type 2133/1866/1600MHz; DIMM Sizes 32GB, 16GB, 8GB, 4GB
Expansion Slots
M.2--Interface: PCI-E 3.0 x4, Form Factor: M Key 2242/2280/22110, supporting SATA devices
Hard Drives

Power
One external 60 watt DC power adapter, one external 84 watt DC power adapter
Input/Output Ports
LAN: Two Gigabit ports and two 10GBase-T ports
IPMI: One dedicated LAN port
USB: Two USB3.0 ports
Display: VGA
Serial ATA: Six SATA3 (6Gbps) ports
DOM: SuperDOM (Disk on Module) power connectors
TPM 2.0 Header
Front Panel

Dimensions
Width 7.6" (193 mm), Height 1.7" (43 mm), Depth 8.9" (226 mm)
1.2 System Features
The following table provides an overview of the main features of the E200-8D. Please refer

