3.5 LED Indicators
LAN LEDs
The Ethernet ports (two 1 GbE and/or two 10 GbE) have two LEDs. On each port, one LED

the speed of the connection.
1GbE LAN LEDs
(Connection Speed Indicator)
LED Color Denition
Off
No connection
or 10 Mb/s
Green 100 Mb/s
Amber 1 Gb/s
IPMI-Dedicated LAN LEDs
A dedicated IPMI LAN is also included on the motherboard. The amber LED on the right of
the IPMI LAN port indicates activity, while the green LED on the left indicates the speed of
the connection. See the table below for more information.
IPMI LAN LEDs
Color Status Denition
Off Off
No
Connection
Green:
Solid
Link/Speed
(Left)
100 Mb/s
Amber
Blinking
Activity
(Right)
Active
IPMI LAN
Activity LEDLink LED
LAN 1/LAN 2
IPMI LAN
(X8ST3-F)
10G LAN Ports Enable/Disable
JPTG1 is used to enable or disable the 10 Gigabit Ethernet ports (LAN3 ~ LAN4).
10Gb Enable/Disable
Jumper Settings
Pin# Denition
1-2 Enabled (Default)
2-3 Disabled
10GbE LAN LEDs
(Connection Speed Indicator)
LED Color Denition
Off
No connection
or 10 Mb/s
Green 10 Gb/s
Amber 1 Gb/s
Gigabit LAN Ports Enable/Disable
JPL1 is used to enable or disable the Gigabit Ethernet ports (LAN1~LAN2).
GbE LAN Enable
Jumper Settings
Pin# Denition
1-2 Enabled (Default)
2-3 Disabled
