Standby Power
The Standby Power header is located at JSTBY1 on the motherboard.
Standby Power
Pin Denitions
Pin# Denition
1 +5V Standby
2 Ground
3 No Connection
Speaker
On the JD1 header, pins 1-3 can be used for the power LED while pins 4-7 can be used for
an external speaker.
Speaker Connector
Pin Denitions
Pin# Denition
1-3 Power LED
4-7 Speaker
I-SGPIO1/I-SGPIO2
Two Serial Link General Purpose Input/Output (SGPIO) headers are used to communicate
with the enclosure management chip in the system.
Serial Link General Purpose
Headers Pin Denitions
Pin# Denition Pin Denition
1 NC 2 NC
3 Ground 4 DATA Out
5 Load 6 Ground
7 Clock 10 NC
NVMe I2C Header
Connector JNVI2C is a management header for the Supermicro AOC NVMe PCI-E peripheral
cards. Connect the I
2
C cable to this connector.
