Chapter 3 Motherboard Connections
VGA Enable/Disable
Jumper JPG1 allows you to enable or disable the VGA port using the onboard graphics
controller. The default setting is Enabled.
VGA Enable/Disable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled
PCI-E Slot SMB Enable (JI
2
C1/JI
2
C2)
JI
2
C1 and JI
2
C2 are used to enable PCI-E SMB (System Management Bus) support to improve
system management for the onboard PCI-E slot.
SMB to PCI-E Slots (JI
2
C1/JI
2
C2)
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
Watch Dog
JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system
when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system
if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for
the application that hangs. Watch Dog must also be enabled in BIOS. The default setting
is Reset. Note: When Watch Dog is enabled, the user needs to write their own application
software to disable it.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset
Pins 2-3 NMI
Open Disabled
