SuperServer E200-9AP User's Manual
Rear I/O Ports
# Description # Description
1. DisplayPort 6. USB1
2. HDMI 7. USB0
3 COM1 8 LAN1
4 USB2 9 LAN2
5. USB3 10 VGA
1
98
7
6
5
4
3
2
10
Rear Features
The chassis rear holds input/output ports.
<Do we want a drawing of the chassis rear? To
point out the power input jack. I don't have one
available--we'll have to get one.>
DisplayPort
DisplayPort, develped by the VESA consortium, delivers digital display and fast refresh rate.
It can connect to virtually any display device using a DisplayPort adapter for devices such
as VGA, DVI or HDMI.
HDMI Port
The HDMI (High-Denition Multimedia Interface) port is used to display both high denition
video and digital sound through an HDMI-capable display.
Figure 1-2. Input/Output Ports on Chassis Rear
