Supermicro X10SRH-CF/CLN4F User Manual

Chapter 2: Installation
2-15
Possible System Memory Allocation & Availability
System Device Size Physical Memory
Remaining (-Available)
(4 GB Total System
Memory)
Firmware Hub ash memory (System BIOS) 1 MB 3.99
Local APIC 4 KB 3.99
Area Reserved for the chipset 2 MB 3.99
I/O APIC (4 Kbytes) 4 KB 3.99
PCI Enumeration Area 1 256 MB 3.76
PCI Express (256 MB) 256 MB 3.51
PCI Enumeration Area 2 (if needed) -Aligned on 256-MB
boundary-
512 MB 3.01
VGA Memory 16 MB 2.85
TSEG 1 MB 2.84
Memory available to OS and other applications 2.84
Populating RDIMM/LRDIMM DDR4 Memory Modules for the E5-
2600v3-based Motherboard
Type
Ranks Per
DIMM
and
Data
Width
DIMM Capacity
(GB)
Speed (MT/s); Voltage
(V);
Slot Per Channel (SPC)
and DIMM Per Channel
(DPC)
1 Slot Per
Channel
2 Slots Per Channel
1DPC 1DPC 2DPC
4Gb 8Gb
1.2V 1.2V 1.2V
RDIMM SRx4 8GB 16GB
2133 2133 1866
RDIMM SRx8 4GB 8GB
2133 2133 1866
RDIMM DRx8 8GB 16GB
2133 2133 1866
RDIMM DRx4 16GB 32GB
2133 2133 1866
LRDIMM QRx4 32GB 64GB
2133 2133 2133
LRDIMM
3DS
†
8Rx4 64GB 128GB
2133 2133 2133
Populating RDIMM/LRDIMM DDR4 Memory Modules for the E5-
2600v4-based Motherboard
Type
Ranks Per
DIMM
and
Data
Width
DIMM Capacity
(GB)
Speed (MT/s); Voltage (V);
Slot Per Channel (SPC) and DIMM Per
Channel (DPC)
1 Slot Per
Channel
2 Slots Per Channel
1DPC 1DPC 2DPC
4Gb 8Gb
1.2V 1.2V 1.2V
RDIMM SRx4 8GB 16GB
2400 2400 2133
RDIMM SRx8 4GB 8GB
2400 2400 2133
RDIMM DRx8 8GB 16GB
2400 2400 2133
RDIMM DRx4 16GB 32GB
2400 2400 2133
LRDIMM QRx4 32GB 64GB
2400 2400 2400
LRDIMM
3DS
8Rx4 64GB 128GB
2400 2400 2400
