Page #16 background image
16
X10SRM-F/-TF User Manual
Note: The table above is continued on the next page.
Motherboard Features
CPU
Intel® Xeon® E5-1600/E5-2600 v3/v4 Series processors (Socket R3-LGA 2011). Up to 145W TDP and 22 cores.
Memory
Four (4) slots support up to 128GB of Registered (RDIMM) or 256GB of Load Reduced (LRDIMM) DDR4 (288-pin) ECC
2400/2133/1866/1600/1333 MHz modules.
Note: 2400MHz is only available with the E5-2600 v4 processor and LRDIMM.
DIMM Size
16GB, 8GB, and 4GB, up to 64GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
Intel® PCH C612
Expansion Slots
Two (2) PCI Express 3.0 x8 slots (CPU1 Slot4, CPU1 Slot5)
Note: Slot4 supports NVMe SSD via AOC
One (1) PCI Express 3.0 x16 slot (CPU1 Slot6)
One (1) M.2 M-key Mini PCI Express 2.0 x4 Connector (JMD1)
Note:
Supports 2242, 2280, and 22110 form factors
Network
For LAN 1/2 ports:
Intel® dual 1GBase-T i350 Ethernet Controller (for X10SRM-F only)
Intel® dual X550 10GBase-T Ethernet Controller (for X10SRM-TF only)
One (1) Dedicated IPMI LAN located on the rear I/O panel
Baseboard Management Controller (BMC)
ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
Graphics
Graphics controller via ASpeed 2400 BMC
Motherboard Features
