Supermicro X11DPU User Manual

13
Chapter 1: Introduction
Connector Description
T-SGPIO3 Serial_Link General Purpose I/O header for S-SATA4/5
USB0/1 Backplane Universal Serial Bus (USB) 3.0 Ports 0/1
USB3/4 Front Accessible USB 3.0 Header for USB 3/4 Connections
USB2 USB 3.0 Type A Header
VGA VGA Port
LED Description Status
LED1 UID (Unit Identier) LED Solid Blue: Unit Identied
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
Memory LED Description Status
LED_P1_A1/LED_P1_A2
Memory Fault LEDs for Memory Module P1_A1/
Memory Module P1_A2
Solid Red: Memory Error Occurs
LED_P1_B1/LED_P1_B2
Memory Fault LEDs for Memory Module P1_B1/
Memory Module P1_B2
Solid Red: Memory Error Occurs
LED_P1_C1/LED_P1_C2
Memory Fault LEDs for Memory Module P1_C1/
Memory Module P1_C2
Solid Red: Memory Error Occurs
LED_P1_D1/LED_P1_D2
Memory Fault LEDs for Memory Module P1_D1/
Memory Module P1_D2
Solid Red: Memory Error Occurs
LED_P1_E1/LED_P1_E2
Memory Fault LEDs for Memory Module P1_E1/
Memory Module P1_E2
Solid Red: Memory Error Occurs
LED_P1_F1/LED_P1_F2
Memory Fault LEDs for Memory Module P1_F1/
Memory Module P1_F2
Solid Red: Memory Error Occurs
LED_P2_A1/LED_P2_A2
Memory Fault LEDs for Memory Module P2_A1/
Memory Module P2_A2
Solid Red: Memory Error Occurs
LED_P2_B1/LED_P2_B2
Memory Fault LEDs for Memory Module P2_B1/
Memory Module P2_B2
Solid Red: Memory Error Occurs
LED_P2_C1/LED_P2_C2
Memory Fault LEDs for Memory Module P2_C1/
Memory Module P2_C2
Solid Red: Memory Error Occurs
LED_P2_D1/LED_P2_D2
Memory Fault LEDs for Memory Module P2_D1/
Memory Module P2_D2
Solid Red: Memory Error Occurs
LED_P2_E1/LED_P2_E2
Memory Fault LEDs for Memory Module P2_E1/
Memory Module P2_E2
Solid Red: Memory Error Occurs
LED_P2_F1/LED_P2_F2
Memory Fault LEDs for Memory Module P2_F1/
Memory Module P2_F2
Solid Red: Memory Error Occurs
