Chapter 1: Introduction
1-7
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Onboard I/O
Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5 •
supported in the Windows OS Environment and RAID0, RAID1, RAID10 sup-
ported in the Linux OS.) (Note 1)
Intel 82576 Gigabit Ethernet controller supports dual Giga-bit LAN ports
•
One VGA Port supported by the Winbond Hermon WPCM450 Controller•
One COM port•
PS/2 mouse and PS/2 keyboard ports•
Up to seven USB 2.0 (Universal Serial Bus) (2 Backpanel USB Ports and 5 •
Front Panel Accessible USB connections)
Super I/O: Winbond W83527HG
•
LSI SAS2 2008 Controller supports eight SAS ports (X8DTH-6/X8DTH-6F only) •
(Note 2)
IPMI 2.0 with full KVM support (X8DTH-6F/iF only) (Note 3)
•
Other
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Ext. ATX 12.00" (L) x 13.00" (W) (304.80 mm x 330.20 mm)•
Note 1: For more information on SATA HostRAID confi guration, please
refer to the Intel SATA HostRAID User's Guide posted on our website @
http://www.supermicro.com/support/manuals/.
Note 2: For more information on IPMI confi guration, please refer to the
Embedded IPMI User's Guide posted on our website @ http://www.super-
micro.com/support/manuals/.
