Chapter 1: Introduction
1-5
X8DTH-6/X8DTH-6F/X8DTH-i/X8DTH-iF Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JI
2
C1/JI
2
C2 SMB to PCI/PCI-E Slots Closed/Closed (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1/2 Enable Pins 1-2 (Enabled)
JPS1 SAS2.0 Enable Pins 1-2 (Enabled) (X8DTH-6/-6F only)
JWD Watch Dog Pins 1-2 (Reset)
Connector Description
Buzzer Onboard Buzzer/Internal Speaker
(SPI) BIOS Onboard BIOS
COM1 Backplane Serial Port
FAN 1-8 System/CPU Fan Headers (Fans 7~8: CPU Fans)
JD1 PWR LED/Speaker Header (Pins 1~3: PWR LED, Pins 4~7:
Speaker)
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPI
2
C Power Supply SMBbus I
2
C Header
JPW1, JPW2/JPW3 24-pin ATX PWR, 8-pin Secondary PWR (See the Warning
on Page 1-4)
KB/MS PS2 Keyboard/Mouse
LAN1/2, Dedicated LAN G-LAN (RJ45) Ports (Dedicated LAN: X8DTH-6F/iF)
I-SATA0 ~ I-SATA5 (Intel South Bridge) SATA Ports
SAS Ports 0~3, 4~7 SAS Ports 0~3, 4~7 (X8DTH-6/6F only)
SMBUS1 System Management Bus Header
SATA-SGPIO-0/SATA-
SGPIO-1
Serial General Purpose I/O Headers for SATA
USB 0/1, 3, 4/5, 6/7 Universal Serial Bus (USB) Ports
VGA VGA Connector
LED Description
DP4 Onboard Standby Power LED LED Indicator (Power LED)
DP5 BMC Activity LED Indicator
DP6 SAS Heartbeat LED Indicator: green (X8DTH-6/ X8DTH-6F only)
DP7 SAS Error LED Indicator: red (X8DTH-6/ X8DTH-6F only)
LED5 SAS Activity LED Indicator (X8DTH-6/ X8DTH-6F only)
