X8DTH-6/X8DTH-6F/X8DTH-i/X8DTH-iF User's Manual
2-5 Control Panel Connectors/IO Ports
The I/O ports are color coded in conformance with the PC 99 specifi cation. See
the picture below for the colors and locations of the various I/O ports.
1. Back Panel Connectors/IO Ports
Back Panel I/O Port Locations and Defi nitions
Back Panel Connectors
Keyboard (Purple)1.
PS/2 Mouse (Green)2.
USB 03.
USB 14.
IPMI_Dedicated LAN (X8DTH-iF/6F only)5.
COM Port 16.
VGA (Blue) 7.
LAN 18.
LAN 29.
1
2
3
4
5
6
7
8
9
X8DTH
Rev. 1.01
