1-8
X9DR3-F/X9DRi-F Motherboard User’s Manual
SCU (Storage Control Unit) Connections
• SCU Ports 0~3, 4~7 (X9DR3-F)
0~3 (X9DRi-F)
• RAID Support RAID 0, 1, 10 (X9DR3-F)
RAID 0, 1, 5, 10 (X9DRi-F)
Integrated IPMI 2.0
• IPMI 2.0 supported by the WPCM450R BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-
232 port
Super I/O
• Winbond Super I/O 83527
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 0/1,
USB 2/3),
• Six (6) USB connections for front access (USB 4/5,
USB 8/9, USB 10/11),
• One (1) Type A USB connection for front access
(USB 7)
BIOS
• 16 MB SPI AMI BIOS
®
SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.5
Power
• ACPI/ACPM Power Management
Management
• Main switch override mechanism
• Keyboard Wake-up from Soft-Off
• Power-on mode for AC power recovery
• Intel
®
Intelligent Power Node Manager (Available
when the NMView Software is Installed)
• Management Engine
PC Health
CPU Monitoring
Monitoring
• Onboard voltage monitors for 1.8V, +3.3V, 3.3VSB,
+5V Standby, 1.35V, 1.5V, Chipset Voltage, and
Battery Voltage.
• CPU 5-Phase switching voltage regulator
