Motherboard Features
CPU
• Dual Intel
®
E5-2600(v2) Series Processors (Socket
R LGA2011); each processor supports four full-width
Intel QuickPath Interconnect (QPI) links (with support
of up to 25.6 GT/s per QPI link and with Data Trans-
fer Rate of up to 8.0 GT/s per direction).
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 1 TB
of Load Reduced (LRDIMM), 512 GB of Registered
(RDIMM) or 128 GB of Unbuffered (UDIMM) ECC/
Non-ECC DDR3 800/1066/1333/1600/1866 MHz
240-pin 4-channel memory modules in 16 DIMM
slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
• Virtualization: VT-x, VT-d, and VT-c
Chipset
• Intel
®
PCH C606/C602
Expansion
• Three (3) PCI Express 3.0 x16 slots (CPU1 Slot2/
CPU2 Slot4/CPU2 Slot6)
• Three (3) PCI Express 3.0 x8 slots (CPU1 Slot1/
CPU1 Slot3/CPU2 Slot5)
Slots
Graphics
• Nuvoton BMC Video Controller (Matrox G200)
Network
• One Intel I350 Gigabit (10/100/1000 Mb/s) Ethernet
Dual-Channel Controller for LAN 1/LAN 2 ports.
• Nuvoton WP450R Base-board Controller (BMC) sup-
ports IPMI_LAN 2.0
I/O Devices
SATA Connections
• SATA Ports Six (6): Two (2) SATA 3.0 and
Four (4) SATA 2.0 Ports
• RAID (Linux) RAID 0, 1, 5, 10
