X9DR3-F/X9DRi-F Motherboard User’s Manual
Warning: To prevent damage to the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect
these power supply connectors to the 24-pin power connector (JPWR3) and two 8-pin
power connectors (JPWR1, JPWR2) on the motherboard. Failure in doing so will void
the manufacturer warranty on your power supply and motherboard.
Slot1, Slot3, Slot5 CPU1 Slot1/CPU1 Slot3/CPU2 Slot5 PCI-Exp. 3.0 x8
T-SGPIO 1/2 Serial_Link General Purpose I/O Headers
BP USB 0/1, 2/3 Back Panel USB 0/1, 2/3
USB 4/5, USB 6, USB
8/9, USB 10/11
Front Panel Accessible USB Connections
VGA Backpanel VGA Port
X9DR3-F/X9DRi-F LED Indicators
LED Description State Status
DM1 BMC Heartbeat LED Green: Blinking BMC Normal
LE1 Standby PWR LED Green: On SB Power On
