Supero X9DR3-F User Manual

Chapter 1: Overview
1-5
X9DR3-F/X9DRi-F Jumpers
Jumper
Description Default Setting
JBT1
Clear CMOS See Chapter 2
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Management Engine (ME) Recovery
Mode Enable
Pins 1-2 (Normal)
JPME2 Management Eingine (ME)
Manufacture Mode
Pins 1-2 (Normal)
JWD Watch Dog Timer Enable Pins 1-2 (Reset)
X9DR3-F/X9DRi-F Connectors
Connectors Description
BT1 Onboard Battery (See Chpt. 3 for Used Battery Disposal)
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1~6, FAN A, FAN B CPU/System Fan Headers
I-SATA 0/1 Intel SB SATA 3.0 Connectors 0/1 (Color: White)
I-SATA 2~5 Intel SB SATA 2.0 Connectors 2~5 (Color: Black)
J22 (JPWR3) ATX 24-Pin Power Connector (See Warning on Pg. 1-6.)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPWR1/2 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JSTBY1 Standby Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JWF1 SATA DOM (Disk on Module) Power Connector
Keyboard/Mouse PS2 Keyboard/Mouse (optional)
LAN1/LAN2 G-bit Ethernet Ports 1/2
(IPMI) LAN IPMI_Dedicated LAN
SCU 0~3, 4~7 Storage Control Unit (SCU) Connectors 0~3, 4~7 (SCU
4~7: X9DR3-F only)
SP1 Onboard Buzzer (Internal Speaker)
Slot2, Slot4, Slot6 CPU1 Slot2/CPU2 Slot4/CPU2 Slot6 PCI-Exp. 3.0 x16
