Supero X9DR3-F User Manual

Chapter 4: AMI BIOS
4-27
Log EFI Status Codes
Select Enabled to log EFI (Extensible Firmware Interface) Status
Codes, Error Codes or Progress Codes. The options are Disabled and
Enabled.
Note: After making changes on a setting, be sure to reboot the system for
the changes to take effect.

BMCNetworkConguration
LAN Channel 1: This feature allows the user to congure the settings for LAN
Channel 1.
UpdateIPMILANConguration
This feature allows the user to decide if the BIOS should congure the IPMI setting
at next system boot. The options are No and Yes. If the option is set to Yes, the
user is allowed to congure the IPMI settings at next system boot:
CongurationAddressSource
This feature allows the user to select the source of the IP address for this computer.
If Static is selected, you will need to know the IP address of this computer and
enter it to the system manually in the eld below. The options are Static and DHCP.
Station IP Address
This item displays the Station IP address for this computer. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253).
Subnet Mask
This item displays the sub-network that this computer belongs to. The value of each
three-digit number separated by dots should not exceed 255.
Station MAC Address
This item displays the Station Mac address for this computer. Mac addresses are
6 two-digit hexadecimal numbers.
Router IP Address
This item displays the Router IP address for this computer. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253).
Router MAC Address
This item displays the Router Mac address for this computer. Mac addresses are
6 two-digit hexadecimal numbers.
