3.2.5 Configuration-Priority Tag Insert/Remove
There are four types of VLAN Tag Control to choose:
1.Remove the VLAN tag from all tagged frame.
2.Insert priority tag into the untagged high-priority frame.
(Set priority field = 7, VID field = 0 for high priority frame.)
3.Insert priority tag into the all untagged frame.
(Set priority field = 7, VID field = 0 for high priority frame;
Set priority field = 0, VID field = 0 for low priority frame.)
4.Don't touch. (Not modify the packet)
Note: The function could be enabled even the VLAN function is not enabled.
Click the “1 / 2”: Page up / Page down check.
Click the “I / M”: Up / Down select.
Click the “0”: Return previous setting sheet.
Click the “Space”: Toggle state.
Click the “F”: to get the latest information.
