Surecom EP-824DX-FS User Manual

Specifications are subject to change without notice.
© 2004 by SURECOM Technology Corporation. All rights reserved.
Page6
2D
1.2 Technical Specification
Standards: IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX/FX Fast Ethernet
ANSI/IEEE Std 802.3 N-way auto-negotiation
IEEE 802.3x flow control for Full-Duplex
Protocol: CSMA/CD
Topology: Star
Transmission Method: Store-and Forward
Transfer Rate
Ethernet:
Fast Ethernet:
10M(half-duplex); 20M(full-duplex)
100M(half-duplex); 200M(full-duplex)
Media
10BASE-T:
100BASE-TX:
100BASE-FX:
UTP Cat.3,4,5 (Max. cable length 100m);
UTP Cat.5 (Max. cable length 100m);
Multi-mode Fiber cable (Max. cable length 2000m)
Single-mode Fiber cable(Max. cable length 30 or 60 km)
No. of Ports: 24 100/10M bps RJ-45 ports
Media Interface Exchange: 24 RJ-45 ports support Auto MDI/MDI-X
Port Module Option: Side-in slot for 100M fiber module
RAM Buffer: Total 2.5M bits per device
Filtering Address Table: 8K
Packet Filtering
/Forwarding Rate:
148800/14800pps
Wire speed per port (for 100Mbps & 10Mbps)
Power: Internal Universal Power,
Input: 90-264V(47-63Hz); Output: 3.3V/7A
Consumption: 10 watts maximum
Temperature
Operating:
Storage:
0℃ ~ 45℃
0℃ ~ 60℃
Humidity
Operating:
Storage:
10% ~ 90%
5% ~ 95%
Conformance: FCC Class A, CE Mark Class A
