1. Introduction
The 24-Port 100/10M N-Way Rack-Mount Smart Switch is the latest design in its N-Way
Switches series for easy installation and high-performance in an environment wheretraffic on the
network and the number of users increase continuously. Provide 24-Port 100/10M Ethernet Switch
support Auto MDI/MDI-X. Small businesses and corporatebranch offices can take full advantage
of 100Mbps Fast Ethernet performance andpreserve existing desktop investment with no changes
required to PCs, NICs, cabling,drivers, or PC configurations.
1.1 Feature and Benefit
Feature
1. Provide 24-Port 100/10M Ethernet Switch to support Auto MDI/MDI-X
2. Provide one fiber slide-in port for expansion the workgroup distance
3. Provide back-pressure in half-duplex and flow control in full-duplex
4. Store-and-forward switching scheme capability supports rate adaptation and ensures data
integrity
5. N-way Auto-negotiation on each RJ-45 port. This allows for auto-sensing of speed
(100/10Mbps) and auto-detecting mode (full-duplex or half-duplex) thereby providing
you with automatic and flexible solutions in your network connections
6. Auto-polarity detection for correction of incorrect polarity on the received twisted-pair
7. Data fowarding rate 148,800 pps per port at 100% of wire-speed
8. Data filtering rate eliminates all error packets, runts, etc. at 148,800pps per port at 100% of wire
speed
9. Conform to IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX /FX, and IEEE 802.3x
flow control for full-duplex standards
10. Provide non-blocking twenty-four ports full-wire speed access
11. Support one fiber slide-in port for expansion with the 24th port
12. Full/half-duplex mode operation on all ports
13. Auto-negotiation capability
14. Source address learning and aging function
15. Provide 8K MAC address and 2.5Mbits SSRAM buffer per device
16. LEDs to indicate Power, link/activity, full-duplex/collision, and speed (10/100Mbps) status
17. Support up to 32 VLAN groups entries for port based VLAN.
(This switch supports maximum of 32 VLAN group entries for setting in default, but it may be
less than 32 entries can be really used sometime which depends on whether you do VLAN
setting with overlap port or not.)
18. Support up to 7 Trunk groups function with load balance and fault tolerance
