TECHNICAL SPECIFICATIONS
OP CIC1200 E Rev4.0 06-09 Chapter 2 7
2
2. TECHNICAL SPECIFICATIONS CIC1200
Operating Mode: Single channel constant power
Independent dual channel constant intensity. Remote control
Output Power: LH200 or NFH: 200W; LH350: 750W;
LH1000/ LH1500: 1200W maximum continuous.
Output Voltage: 380V DC open circuit (max)
Output
Regulation:
+/- 1% over selected mains input range
Lamp Ignition: 20kV start with automatic shut down following ignition.
Active current limit during warm-up.
Remote start unit with polarity switch. Single pulse ignition.
Mains Input: 230V +/- 10% 50/60 Hz; L+N+PE or L1+L2+PE
max. power: 1600W
Exchangeable fuses in rear panel: 2x 10A slow-blow, 5x20 mm.
Optical Sensor:
(for CI-mode)
Dual channel using silicon photodiodes with thin film dielectric or selected glass
absorption filters for 220, 240, 320, 365 and 405 nm wavelengths.
Optical Control:
(for CI-mode)
Digital meter: 0 - 100mW/cm2 front panel channel selected. Front panel level
set and UV-probe calibration.
Size:
without remote start unit
Length: 540 mm [21,25“]
Width: 260 mm [10,25“]
Height: 152 mm [6,0“]
Weight:
without remote start unit
21 kg (46 lbs)
Ambient Conditions • Preferred application in clean room class 10000 or better
• Environmental limits: indoor use only,
Temperature range: +5°C to +40°C (storage and transport condition: -10°C
to +50°C)
Relative humidity: max. 80% non-condensing, up to 31°C, diminishing to 50%
at 40°C,
• Altitude max. 2000 m
