SUSS CIC1200 - Page 18

Condensed Operation Instructions
Operation
Functionality
Press Key For Time in
Seconds
Additional
Key
Left Display
LIGHT INTENSITY
[mW/cm2]
Right Display
LAMP POWER
[W]
Store with
Key
Remarks
Calibration of Channel 1 (with manu- ally assigned values)
3x CALIB T > 1s + or -
START
CAL
(blinks) XXXX
STO
EXT1 XXXX RED
CALIB
Calibration of Channel 2 (with manu- ally assigned values)
4x CALIB T > 1s + or-
START
CAL
(blinks) XXXX
STO
EXT2 XXXX RED
CALIB
Adjust Intensity: Channel 1 and Chan- nel 2 (CP-Mode or CH1 or CH2-Mode)
CHANGE DISPLAY SET CH1/ CH2
T > 1s
+ or - (blinks) XXXX XXXX
SET CH1/ CH2
Switch the green LED in annunciator group DIS
-
PLAY with CHANGE DISPLAY from Channel 1 to Channel 2
Choose Constant Intensity Mode (CI- MODE)
CH1 or CH2
XXXX XXXX
Calibration and adjust- ment of intensity (Set CH1/CH2) has to be done before
Adjustment of Light sensor input Channel 1
5x CALIB
T > 1s START XX%
S10K S10K CALIB
Adjust max. 95% with max. lamp power
Adjustment of Light sensor input Channel 2
6x CALIB
T > 1s START XX%
STO
S20K S20K RED CALIB
Adjust max. 95% with max. lamp power
Measurement with UV- Probe input
7x CALIB
T > 1s START XXXX
UVPR UVPR
Exit with CALIB Display shows FINISH
Erase calibration data for CH1
8x CALIB
T > 1s START
START
CAL1 CAL1
DONE
STO
RES RES? RED
CALIB
Erase calibration data for CH2
9x CALIB
T > 1s
CAL2 CAL2
DONE
STO
RES RES? RED
CALIB
Leave calibration menu 10x CALIB T > 1s START EXIT Reset Error Messages RESET T > 1s
