FI SYSTEM AND INTAKE AIR SYSTEM 4-53
FUEL PUMP INSPECTION
Turn the ignition switch ON and check that the fuel pump oper-
ates for few seconds.
If the fuel pump motor does not make operating sound, replace
the fuel pump assembly or inspect the fuel pump relay and tip
over sensor.
FUEL DISCHARGE AMOUNT INSPECTION
"
Gasoline is highly flammable and explosive.
Keep heat, spark and flame away.
• Lift and support the fuel tank with its prop stay. (4-51)
• Disconnect the fuel feed hose 1 from the fuel pump.
• Connect a proper extension fuel hose 2 to the fuel pump.
• Disconnect the battery - lead wire.
• Disconnect the ECM lead wire couplers 3 and 4.
• Push the lock A to pull out the power source lead wire.
To Next Page
