8-30 SERVICING INFORMATION
TIGHTENING TORQUE
ENGINE
ITEM N
.
m kgf
.
m lb-ft
Exhaust pipe bolt 23 2.3 16.5
Muffler mounting nut 23 2.3 16.5
Speed sensor rotor bolt 20 2.0 14.4
Engine sprocket nut 115 11.5 83.2
Engine mounting bolt and nut (M:12) 75 7.5 54.0
(M:10) 55 5.5 39.8
Engine mounting thrust adjuster 10 1.0 7.0
Engine mounting thrust adjuster lock nut 45 4.5 32.5
Engine mounting pinch bolt 23 2.3 16.5
Cylinder head cover bolt 14 1.4 10.0
Spark plug 11 1.1 8.0
Cam chain guide bolt 10 1.0 7.0
Camshaft journal holder bolt 10 1.0 7.0
Cam chain tension adjuster cap bolt 23 2.3 16.5
Cam chain tension adjuster mounting bolt 10 1.0 7.0
Cylinder head side bolt 14 1.4 10.0
Cam chain tensioner bolt 10 1.0 7.0
Cylinder head bolt (M:10) 46 4.6 33.3
(M:6) 10 1.0 7.0
PAIR reed valve cover bolt 10 1.0 7.0
Water jacket plug 9.5 0.95 6.9
Water inlet cover bolt 10 1.0 7.0
Clutch cover bolt 10 1.0 7.0
Clutch sleeve hub nut 150 15.0 108
Clutch spring set bolt 10 1.0 7.0
Starter clutch cover bolt 10 1.0 7.0
Starter idle gear cover bolt 10 1.0 7.0
Valve timing inspection plug 11 1.1 8.0
Starter clutch bolt 55 5.5 40.0
Generator cover bolt 10 1.0 7.0
Generator rotor bolt 100 10.0 72.3
Generator stator set bolt 10 1.0 7.0
Gearshift cam stopper bolt 10 1.0 7.0
Gearshift cam stopper plate bolt 10 1.0 7.0
Oil pressure switch 14 1.4 10.0
Crankcase bolt (M:6) 11 1.1 8.0
(M:8) 26 2.6 19.0
(M:9) 32 3.2 23.0
Oil gallery plug (M:6) (M:10) 11 1.1 8.0
(M:16) 35 3.5 26.5
Oil drain plug 23 2.3 16.5
