9-6 EMISSION CONTOROL INFORMATION
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING
PAIR valve vacuum hose
(530 mm)
PAIR valve
10 N
.
m (1.0 kgf
.
m, 7.5 lb-ft)
PAIR reed valve
PAIR valve hose L (30 mm)
Matching mark
PAIR cleaner hose
PAIR valve hose R (50 mm)
To throttle body (N0.4 cylinder)
Air cleaner box
