16 VL1500K5 (’05-MODEL)
ENGINE INSTALLATION
Installation is in the reverse order of removal procedure.
• Tighten the exhaust pipe bolts and muffler mounting bolts to the specified torque.
'
• Adjust the following items to the specification.
* Engine oil (!VL1500 Service Manual 2-6)
* Throttle valve synchronization (!Page 114)
* Throttle cable play (!Page 9)
* Engine idle speed (!Page 8)
* Automatic decompression cable (!VL1500 Service Manual 2-8)
* Clutch air bleeding (!VL1500 Service Manual 6-59)
* Wiring harness, cables and hoses (!Page 144)
Apply PERMATEX 1372.
Apply PERMATEX 1372.
Replace the gaskets with the new ones.
