Swarm M138 - 3 Mechanical Specification; Modem Dimensions

3 Mechanical Specification
3.1 Modem Dimensions
The overall dimensions of the Modem and its weight are summarized in Table 3.
Parameter
Value
Length
51.0 mm
Width
30.0 mm
Height
5.3 ±0.1 mm
Weight
9.6 g
Table 3: Modem Mechanical Dimensions and Weight.
Figure 1: Modem front and back views.
November 2021 Swarm M138 Modem Manual - Rev 1.00 10/77
