4 Electrical Interfaces
The following subsections contain information for the electrical interfaces of the Modem.
4.1 User Host Device
The user host device provides the following connections to the Modem:
● DC power supply input: 3.0V to 5.5V, (1600 mA
peak
at 3.3V)
○ EMI/RFI shielding CAN is required if using a switching DC power supply in order
to contain radiated emissions
○ Additional filtering of the power supply is highly recommended
■ See Design Guidance for best practices
● Data interface
○ 3.3V Serial Data Interface
● Satellite signal (Use the provided U.FL connector labeled VHF)
● GPS signal (Use the provided U.FL connector labeled GPS)
● GPIO1 (optional)
November 2021 Swarm M138 Modem Manual - Rev 1.00 12/77
