Swegon CASA W3 Smart User Manual

EN
www.swegonhomesolutions.com
72
Air cooler for cooling the supply air
• For 160 mm ducts; SDCW 160 (LVI-no
7906555). Suitable for use with among
others CASA Smart W3 and R3 ventilation
unit. Thanks to the height of 255 mm in
can fit in a suspended ceiling, among oth-
ers in apartment blocks. Pipe connection
Cu 10 mm.
• For 200 mm ducts; SDCW 200 (LVI-no
7906556). Suitable for use with among
others CASA Smart W4 and R5 ventilation
unit. Pipe connection Cu 22 mm.
• For 250 mm ducts; SDCW 250F (LVI-no
7906557). Suitable for use with among
others CASA Smart R5, W5 and W9
ventilation unit. Body fully insulated, wall
mounting bracket/ceiling mounting frame
and coarse filter supplied. Pipe connection
Cu 22 mm.
Air heater for heating the supply air
• For 125 mm ducts; SDHW 125 (LVI-no.
7906558). Suitable for use with among
others CASA Smart W3 and R3 ventilation
unit. Thanks to the height of 255 mm in
can fit in a suspended ceiling, among oth-
ers in apartment blocks. Pipe connection
Cu 10 mm.
• For 160 mm ducts; SDHW 160 (LVI-no.
7906559). Suitable for use with among
others CASA Smart W4, W5 and R5 venti-
lation unit. Pipe connection Cu 10 mm.
Air heater in combination with ground
source heat pump
• For 200 mm ducts; SDHW 250F (LVI-no.
7906597). Suitable for use with among
others CASA Smart R3, R5, W3, W4,
W5 and W9 ventilation unit. Body fully
insulated, wall mounting bracket/ceiling
mounting frame and coarse filter supplied.
Pipe connection Cu 22 mm.
Electric air heater for outdoor air duct
• For 125 mm duct; SDHE125-1T (LVI-no.
7906723).
• For 160 mm duct; SDHE160-1T (LVI-no.
7906724).
• For 200 mm duct; SDHE200-1T (LVI-no.
7906725).
