Fast-transient
immunity test/
Bursts acc. to IEC
61000-4-4
± 2 kV for power
supply lines
± 1 kV for input
and output lines
± 1 kV for power
supply lines
Not applicable
The quality of the supply
voltage should correspond
to that in typical business or
hospital surroundings.
Surges
acc. to IEC 61000-
4-5
± 1 kV voltage
Outer conductor -
outer conductor
± 2 kV voltage
outer conductor
- earth
± 1 kV voltage
Outer conductor -
outer conductor
Not applicable
The quality of the supply
voltage should correspond
to that in typical business or
hospital surroundings.
Voltage dips, short
interrupons
and uctuaons in
the supply voltage
Acc. to IEC 61000-
4-11
< 5 % Ut
< (> 95 % dip in Ut
) for 1/2 period
40 % Ut (60 %
dip in Ut ) for 5
periods
70 % Ut (30 %
dip in Ut ) for 25
periods
< 5 % Ut (> 95 %
dip in Ut ) for 5 s
0 % Ut
< (> 95 % dip in Ut
) for 1/2 period
40 % Ut (60 %
dip in Ut ) for 5
periods
70 % Ut (30 %
dip in Ut ) for 25
periods
0 % Ut (> 95 % dip
in Ut ) for 5 s
The quality of the supply
voltage should correspond
to that in typical business or
hospital surroundings. If the
user of the iMRS requires
uninterrupted funconing,
even when interrupons
in the power supply occur,
it is recommended to feed
the iMRS from an uninter-
ruptable power supply or a
baery.
Magnec eld at a
supply frequency
(50/60 Hz) acc. to
IEC 61000-4-8
3 A/m 3 A/m Magnec elds at mains fre-
quency should correspond to
values typical of a business
or hospital environment.
Remark: Ut is the mains AC voltage before the applicaon of the test level.
