6
Send
This app allows you to send channel levels to one or more devices
connected via the DMX and/or Ethernet connectors. Channel/address
levels can be viewed in decimal, hex or percentage notation.
Navigation
• Choose channel/address:
• Change the channel level:
• View the Settings page:
• View the Routing page:
[Routing]
See page 7
• Return to previous page:
Settings page
• Clear All Channels: Returns all channels to zero
• Show Level As: Decimal / Hex / Percent
• Refresh Rate: 5Hz / 10Hz /15Hz / 20Hz / 25Hz / 30Hz /
35Hz / 40Hz / 44Hz
Routing
This page manages which protocols (DMX, Art-Net and/or sACN) are sent.
More than one can be enabled. See page 7.
