Sylvac S25 - Quickstart of the Sylvac-Reflex Scan Software; Touch Panel

10
QUICKSTART
4. QUICKSTART OF THE SYLVAC-REFLEX SCAN
+
SOFTWARE
1 - Turn on the machine using the ON/OFF button
2 - Start up the computer
3 - Launch the Sylvac-Reflex Scan+ software by clicking on the
icon
4 - The below window will be displayed on your screen. Log in as a supervisor using the password “123”.
5 - Please refer to Reflex SCAN+’s manual for all features and details.
4.1. Software
4.2. Touch panel
Home screen
Reflex-Click mode;
part recognition /
auto-measure
Start/Stop*
Replay mode
Tailstock clamping
force indicator
Working temperatureMachine light on/off
Settings
4.2.1 Main screen
Increment
force
