7. TECHNICAL DATA
SPECIFICATIONS Metric Inches
Overall Dimensions
Machine (H x L x P) 590 x 460 x 521 mm 23.2 x 18.11 x 20.51 inch
Mass, without table
Machine with centres ≈ 73 kg ≈ 160.93 lbs
Packed machine
Operating temperature
Storage temperature 5 to 45 °C 40 to 115 °F
Relative humidity (storage) 80% max 80% max
Operating temperature 10 to 40 °C 50 to 105 °F
Relative humidity (operating)
(non-condensing)
80% max 80% max
Power
Power-supply 24VDC, 11.67A (external powering provided with the machine: 100-240 VAC / 48 VDC)
Power consumption (while scanning) ~ 200W
Performances (at 20° ±1°C)
Resolution up to 0,1 μm 4e-6 in
Highest repeatability (2s = 95%)
Lengths 2δ=0.8 μm 2δ= 31.49606µin
Diameters 2δ=0.5 μm 2δ= 19.68504µin
Precision MPE (D and L in mm)
Lengths (3 + L[mm]/200) μm ± (0,11+L/5080)/1000 in
Diameters (0.9 + D[mm]/100) μm ± (0,03+D/2540)/1000 in
Additional data
Maximum volume of the part (between
centres)
Measuring range Ø 26 x L 200 mm Ø 1.2 x L 7.84 in
Weight of the part 3 kg 6.61 lbs
Maximal displacement speed
Main axis (X-axis) 100 mm/s (measure) 3937,01 in/s (measure)
Rotation 360°/s
Measurement cycle duration (e.g. static
measurement of 20 dimensions)
6s
Noise level (for maximum capacity part length) LpA <70 dB (A)
The SCAN S25T includes a tilting for thread measurement (30°).
All indicated values are based on the results obtained from clean and ground components measured at 20°C. They may be altered by
the component shape and surface finish.
7.1. Machine S25/S25T
To Next Page
