QUICKSTART
1. UNPACKING AND INSTALLATION OF THE MACHINE
1.2.Unpacking the machine
To unpack the machine, follow the steps below :
Keep all the packing parts
for an eventual sending !
The procedures of this quickstart are valid for the machines Sylvac SCAN S25(T).
1) Remove the box.
1.1. Necessary material for the installation
- Allen key 3mm
- Allen key 4mm
- Combination wrench 13mm
2) Result
3) Open the 2 lateral sides of the ma-
chine to gain access to the ma-
chine lock on the transport.
4) Uncoupling the machine / palle-
ting by unscrewing the 2 M8 locking
nuts linking the machine to the pallet
(wrench 13mm). Machine ready to be
installed.
