13
QUICKSTART
After positionning the mobile optical carriage in position : ’’Park axes for trans-
port’’ in the software. Check the status of the Tilt Motor as the second image
above. If it is Red, then the tilt axis is free to move and you can freely mount
the blocking pins. Disconnect the machine from PC/screen, and clamp down
mechanically the machine with the original provided locking Slide part.
6. PACKING UP THE MACHINE (MOVING OR SENDING THE MACHINE)
6.1.Secure the moving parts
Connect the machine to the computer. In the Sylvac-Reflex Scan+ software, set the mobile part (optical carriages) in
position : ’’Park axes for transport’.
The machine will move into the correct position. When it is in the correct position, a warning message will tell you to fit
the correct accessory to hold the mobile elements in place. Press OK.
6.2.Affix the safety components
Use the software to settle the foam
between headstock and tailstock to
avoid shocks.
